There are three ways to set up communication in a microservices-oriented application:

  • synchronous, in which communication happens in real time;
  • asynchronous, in which communication happens independent of time; and
  • hybrid, which supports both.

Often, hybrid microservices architecture is overlooked when comparing synchronous and asynchronous communication, but it's an important model to know. Here's how these microservices architectures work.

Synchronous

A synchronous microservice is one in which data moves to and from an endpoint of a service in a blocking interaction. A typical example of a synchronous data exchange is an HTTP request/response interaction, seen in Figure 1 below. When a request is made to an endpoint under HTTP, the caller is locked in the interaction until a response is received.

Synchronous inter-service communication diagram
Figure 1. An HTTP request/response interaction is synchronous.

The caller might receive the response in a mere millisecond or in a few seconds. Regardless of the application latency, the caller cannot move forward to the next task until the response is received. REST is a good example of a synchronous microservice.

Asynchronous

An asynchronous microservice is one in which a request to a service and the subsequent response occur independently from each other. The general practice for implementing an asynchronous microservice is to use a message broker technology, such as Kafka or RabbitMQ, to act as a go-between for services, as seen in Figure 2 below. One service will publish a message to another service using the message broker.

Asynchronous inter-service communication diagram
Figure 2. Microservices that communicate in an asynchronous manner can use a protocol such as AMQP to exchange messages via a message broker.

The intended service receives the message in its own time. The sending service is not locked to the broker. It simply fires and forgets.

Hybrid

A hybrid microservice is one that supports both synchronous and asynchronous interactions. For example, a hybrid service will support both HTTP and messaging protocols.

As shown in Figure 3 below, Microservice B accepts an HTTP request from Microservice A. But, before Microservice B responds to Microservice A, it sends a message to Microservice C. The message sent to Microservice C mostly likely will contain information that is relevant to the concern of Microservice C.

Hybrid inter-service communication diagram
Figure 3. A hybrid microservice-oriented application architecture uses both synchronous and asynchronous communication mechanisms.

Microservice B sends the message to Microservice C asynchronously, without having to wait for a response from Microservice C. This hybrid pattern has a definite advantage for those concerned with the speed of interactions.

GraphQL is a technology that supports hybrid microservices. Callers can interact with a microservice published under GraphQL via its synchronous query and mutation technology. But a caller can also receive a message asynchronously from the microservice using GraphQL subscriptions.
